/ inFinit Made-to-measure
Product timing available by request
Design: OM + Bartenbach GmbH
Pendant direct and indirect module with housing made of aluminium with electrostatic 100% polyester paint.
Direct light: Linear extruded lenses (Lightstream) combined with a secondary reflector, integrated into an extruded aluminium profile.
Indirect light: Linear lenses for batwing effect protected by a transparent polycarbonate diffuser.
Color temperature 4000K CRI >90
Beam Angle Flood 64° / batwing LOR 80%
UGR <16 Colour deviation 2-step MacAdam
Light source power 14+28W Life time >50.000h, L80/B10
Light source flux 1800+1720lm Control DALI
Light source efficiency 84lm/W IP rating 20
Luminaire power 17,1+34,1W IK rating -
Luminaire flux 1440+1360lm Weight
Luminaire efficiency 55lm/W Wiring 230Vac | 50/60Hz
Color temperature 4000K
Beam Angle Flood 64° / batwing
UGR <16
Light source power 14+28W
Light source flux 1800+1720lm
Light source efficiency 84lm/W
Luminaire power 17,1+34,1W
Luminaire flux 1440+1360lm
Luminaire efficiency 55lm/W
CRI >90
LOR 80%
Colour deviation 2-step MacAdam
Life time >50.000h, L80/B10
Control DALI
IP rating 20
IK rating -
Weight
Wiring 230Vac | 50/60Hz
Last Update: 21 November, 2022

/ Downloads

Technical Data
Data sheetInstallation instructionsTender textPhotometric data: LDTPhotometric data: IESTechnical drawing: 2D / 3DCertificationsPhoto selection
Download All

/ Warnings

For the specific supply of "DALI 2" drivers, please contact: support@om-light.com

Choose the length and layout of the system exactly as you want it, to model the right lighting functions for different tasks. For further information please contact: support@om-light.com
