/ OS  Pendant


                                    Design: Eduardo Souto de Moura
Emergency pendant luminaire with body made of steel and electrostatic 100% polyester paint with textured finish.
Single sided pictogram, with polycarbonate structure and adhesive film, included.
The same luminaire allows maintained or non-maintained mode.
Luminaire with self-testing mode.
Prepared for remote control (rest mode).
3-hours autonomy.
Compliant with the following standards:
EN60598-2-22 / EN60598-1
                                    Emergency pendant luminaire with body made of steel and electrostatic 100% polyester paint with textured finish.
Single sided pictogram, with polycarbonate structure and adhesive film, included.
The same luminaire allows maintained or non-maintained mode.
Luminaire with self-testing mode.
Prepared for remote control (rest mode).
3-hours autonomy.
Compliant with the following standards:
EN60598-2-22 / EN60598-1
| Color temperature | 5000K | CRI | - | |
| Beam Angle | LOR | 19% | ||
| UGR | - | Colour deviation | - | |
| Light source power | 2,4W | Life time | >50.000h, L80/B10 | |
| Light source flux | 340lm | Control | - | |
| Light source efficiency | 142lm/W | IP rating | 44 | |
| Luminaire power | 3,1W | IK rating | 07 | |
| Luminaire flux | 65lm | Weight | 2Kg | |
| Luminaire efficiency | 21lm/W | Wiring | 230Vac | 50/60Hz |
| Color temperature | 5000K |
| Beam Angle | |
| UGR | - |
| Light source power | 2,4W |
| Light source flux | 340lm |
| Light source efficiency | 142lm/W |
| Luminaire power | 3,1W |
| Luminaire flux | 65lm |
| Luminaire efficiency | 21lm/W |
| CRI | - |
| LOR | 19% |
| Colour deviation | - |
| Life time | >50.000h, L80/B10 |
| Control | - |
| IP rating | 44 |
| IK rating | 07 |
| Weight | 2Kg |
| Wiring | 230Vac | 50/60Hz |
Last Update: 21 November, 2022
                                    / Downloads
/ Accessories
 Mandatory
54036 Pendant direct fitting acessoryOptional
56051 Clear Base DALI
