Nub
Flush
/ About Nub Flush
Design: O/M + Bartenbach GmbH
Ceiling-recessed luminaire with aluminium die-cast body with electrostatic 100% polyester paint finish.
IP65 protection level.
Focal-lens with complex surfaces to provide a focal point through an 8mm aperture for low glare illumination.
Supplied with fermacell® plasterboard fiber recessing accessory.
Optical accessories available separately and positioned at the factory
Driver to be ordered separately.
Light Effect
Medium
Flood
Finishes
.02 Black/ Filter Options
/ Nub Flush
No results were found
Color Temperature
Luminaire Dimension
Beam Angle
Light Source Power
UGR
Light Source Flux
Luminaire Flux
Product
code
code
| Color Temperature | Luminaire Dimension | Beam Angle | Light Source Power | UGR | Light Source Flux | Luminaire Flux | Product code |
|---|---|---|---|---|---|---|---|
| 2700K | 8mm | Medium 35° | 5,6W | <19 | 460lm | 240lm | 60012 |
| 2700K | 8mm | Flood 58° | 5,6W | <28 | 460lm | 270lm | 60013 |
| 3000K | 8mm | Medium 35° | 5,6W | <19 | 460lm | 240lm | 60014 |
| 3000K | 8mm | Flood 58° | 5,6W | <28 | 460lm | 270lm | 60015 |
| 4000K | 8mm | Medium 35° | 5,6W | <19 | 490lm | 260lm | 60016 |
| 4000K | 8mm | Flood 58° | 5,6W | <28 | 490lm | 290lm | 60017 |
| Product code |
|
|---|---|
| 2700K / 8mm / Medium 35° / 5,6W / <19 / 240lm | 60012 |
| 2700K / 8mm / Flood 58° / 5,6W / <28 / 270lm | 60013 |
| 3000K / 8mm / Medium 35° / 5,6W / <19 / 240lm | 60014 |
| 3000K / 8mm / Flood 58° / 5,6W / <28 / 270lm | 60015 |
| 4000K / 8mm / Medium 35° / 5,6W / <19 / 260lm | 60016 |
| 4000K / 8mm / Flood 58° / 5,6W / <28 / 290lm | 60017 |
