inVision45
Surface/Pendant Wallwasher
inVision45
Surface/Pendant Wallwasher
/ About inVision45 Surface/Pendant Wallwasher
Finishes
.01 White
.02 Black/ Filter Options
/ inVision45 Surface/Pendant Wallwasher
No results were found
Color Temperature
Luminaire Dimension
Beam Angle
Light Source Power
UGR
Light Source Flux
Luminaire Flux
On/Off Code
DALI Code
| Color Temperature | Luminaire Dimension | Beam Angle | Light Source Power | UGR | Light Source Flux | Luminaire Flux | On/Off Code | DALI Code |
|---|---|---|---|---|---|---|---|---|
| 2700K | 611mm | Wallwasher | 13W | - | 1205lm | 915lm | 65548 | 65560 |
| 2700K | 611mm | Wallwasher | 26W | - | 2410lm | 1830lm | 65549 | 65561 |
| 2700K | 911mm | Wallwasher | 19W | - | 1810lm | 1375lm | 65552 | 65564 |
| 2700K | 911mm | Wallwasher | 38W | - | 3620lm | 2750lm | 65553 | 65565 |
| 2700K | 1211mm | Wallwasher | 26W | - | 2410lm | 1830lm | 65556 | 65568 |
| 2700K | 1211mm | Wallwasher | 51W | - | 4825lm | 3665lm | 65557 | 65569 |
| 3000K | 611mm | Wallwasher | 13W | - | 1285lm | 975lm | 65572 | 65584 |
| 3000K | 611mm | Wallwasher | 26W | - | 2570lm | 1955lm | 65573 | 65585 |
| 3000K | 911mm | Wallwasher | 19W | - | 1925lm | 1465lm | 65576 | 65588 |
| 3000K | 911mm | Wallwasher | 38W | - | 3850lm | 2925lm | 65577 | 65589 |
| 3000K | 1211mm | Wallwasher | 26W | - | 2570lm | 1955lm | 65580 | 65592 |
| 3000K | 1211mm | Wallwasher | 51W | - | 5135lm | 3900lm | 65581 | 65593 |
| 4000K | 611mm | Wallwasher | 13W | - | 1420lm | 1080lm | 65596 | 65608 |
| 4000K | 611mm | Wallwasher | 26W | - | 2845lm | 2160lm | 65597 | 65609 |
| 4000K | 911mm | Wallwasher | 19W | - | 2135lm | 1620lm | 65600 | 65612 |
| 4000K | 911mm | Wallwasher | 38W | - | 4265lm | 3240lm | 65601 | 65613 |
| 4000K | 1211mm | Wallwasher | 26W | - | 2845lm | 2160lm | 65604 | 65616 |
| 4000K | 1211mm | Wallwasher | 51W | - | 5690lm | 4325lm | 65605 | 65617 |
| On/Off Code | DALI Code | |
|---|---|---|
| 2700K / 611mm / Wallwasher / 13W / - / 915lm | 65548 | 65560 |
| 2700K / 611mm / Wallwasher / 26W / - / 1830lm | 65549 | 65561 |
| 2700K / 911mm / Wallwasher / 19W / - / 1375lm | 65552 | 65564 |
| 2700K / 911mm / Wallwasher / 38W / - / 2750lm | 65553 | 65565 |
| 2700K / 1211mm / Wallwasher / 26W / - / 1830lm | 65556 | 65568 |
| 2700K / 1211mm / Wallwasher / 51W / - / 3665lm | 65557 | 65569 |
| 3000K / 611mm / Wallwasher / 13W / - / 975lm | 65572 | 65584 |
| 3000K / 611mm / Wallwasher / 26W / - / 1955lm | 65573 | 65585 |
| 3000K / 911mm / Wallwasher / 19W / - / 1465lm | 65576 | 65588 |
| 3000K / 911mm / Wallwasher / 38W / - / 2925lm | 65577 | 65589 |
| 3000K / 1211mm / Wallwasher / 26W / - / 1955lm | 65580 | 65592 |
| 3000K / 1211mm / Wallwasher / 51W / - / 3900lm | 65581 | 65593 |
| 4000K / 611mm / Wallwasher / 13W / - / 1080lm | 65596 | 65608 |
| 4000K / 611mm / Wallwasher / 26W / - / 2160lm | 65597 | 65609 |
| 4000K / 911mm / Wallwasher / 19W / - / 1620lm | 65600 | 65612 |
| 4000K / 911mm / Wallwasher / 38W / - / 3240lm | 65601 | 65613 |
| 4000K / 1211mm / Wallwasher / 26W / - / 2160lm | 65604 | 65616 |
| 4000K / 1211mm / Wallwasher / 51W / - / 4325lm | 65605 | 65617 |
